Applicable Scope:

1.Can be used under high or slight vacuum condition;

2.Distillation and fractionation on the  high  boiling  point  and high;

3.Can be used as concentration equipment for the  material  with high boiling point. high viscosity, high solid  content and high thermal sensitivity;

4.Can be used as reactor the internal rotation shaft can be regarded as hollow stirrer  .and can be  used as  reflux reactor For distillation, can be used as titration reaction for timely heating or cooling;

5.The circumstances that needs to inc『ease the concentration  ratio to the maximum.

6.lt is  widely   used in   fine chemicals. pharmaceuticals, light industry，foodstuff, alcohol. and beverage and environment protection areas.

Technology Advantage:

1.Maximum concentration ratio (more than 30 times), maximum final concentration (90- 100%)

2. Achieves the maximum solvent recovery at maximum final concentration

3. Discharges  solid  directly  through concentration  equipment.  the  advantage  of energysaving is also obvious.

Features:

1.Thin evaporation film will be formed on the internal surface of the equipment. no dead corner.  no pressure drop, no resistance.

2. With same volume, able to achieve more than three times evaporation eff1c1ency compared to other evaporators.

3.Thermal efficiency is more than 90%.

4.The final concentration percentage is high, also even under high concentration circumstance, it is not easy to cause scale, especially applicable for high concentration circumstance，「educing the transportation and the later cleaning cost dramatically.

5.Solid is able to be discharged/produced directly for several special material.

6.Distillation or concentration operation can be continuous. hemicontinuous or discontinuous.

7.Working efficiency can  be increased  by 5%-15%, high  recovery,  good  quality  and no damage on the material.

8.Able to work either under normal pressure and 1OOPa-1Pa vacuum circumstance O「 WO「k as re-boiler under positive or negative pressure  circumstance.

9.The cold hot agent  is able to go through  inside the  internal hollow rotating  components.

10.Overcome the defects as thick film. scaling or  material mixing.

11.Small temperature difference, the evaporation can take place when the temperature equal to 5degree.

FXGG High   Efficient Evaporator Specification:
